Showing 33–48 of 65 results
-
It can operate four electric linear actuators to run completely synchronously.
Wired control via a control handle.
Wireless control via a remote.
Two function buttons: Up and Down.
With reset button.
-
Optional working voltage: 6V DC or 12V DC or 24VDC
Optional stroke: 10/17.5/21/25/30/50/75/100/150/200mm
Installation length: 55mm + Stroke
Optional speed: 5mm±1mm/s, 7mm±2mm/s, 9.5mm±2mm/s, 15mm±3mm/s, 30mm±5mm/s, 50mm±10mm/s, 150mm±20mm/s
The above is the speed at no load, and the actual working speed will gradually slow down as the load increases.
Max Load capacity: 188N / 19 Kgs / 42 lbs at 5mm/second
Linear actuator can get maximum load capacity when it operates in the vertical direction, and the pulling force is less than
pushing force.
No-load current: 0.02~0.04A at 12V or 0.04~0.08A at 6V
Full load current: 0.2~0.3A at 12V or 0.4~0.6A at 6V
Outer tube diameter: 12*16mm
Telescopic tube diameter: 6*9mm
Mounting holes diameter: 4mm
Housing Material: Polyamide
Stroke Rod Material: Aluminum Alloy
Outer Tube Material: Aluminum Alloy
Gear Material: Steel Alloy
Motor Type: Brushed DC Motor
Duty Cycle: 10%
Plug Standard: Ordinary Two-core Wire
Certifications: CE
Environment temperature: -26℃ to 85℃
Operating Noise: about 45dB~55dB (Linear actuators with different parameters will have different noise levels.)
IP rating: IP54
-
1. Exquisite, concise appearance design
2. Slip-type installation for a variety of window type,
3. Smooth, smooth power output
4. With electronic control overload protection device
5. Synchronous control box can be used to synchronize the operation of multiple motors
6. More than 2,000 launch and pullback tests
7. Travel can be customized according to customer needs
-
*Voltage：12/24V
*Max load：5000N
*Max No-load speed：9.0MM/S
*Stroke Range：30-1000MM
*Noise： ≦55dB
*Waterproof level：IP66
*Built-in limit switch
*Duty Cycle：10%
*Application：RV roof lift, Yacht, Medical equipment lifting, Solar tracking,etc
Option
*Dual Hall Sensor
*Limit Switch signal Output
-
■ SLA52M is a powerful in-line linear actuator with max load capacity 6000N.
■ Thanks to its clean design, high load capacity, IP67M protection, synchronous working, SLA52M is ideal for outdoor applications where the actuators will be visible, such as skylight, smoke vent system, yacht automation, agricultural machine
- Voltage(V):12V / 24V
- Max. Power(W): 120W
- IP rating: IP67M
- Max Load:6000N
- Min Stroke(mm): 20mm
- Max Stroke(mm): 500mm
- No load current(A): ≤1.6 / ≤0.8
- Load current(A): ≤10 / ≤5
- Color: Black
- Noise on load (dB): 75dB
- Working duty(S2): Work 2 minutes and rest 18 minutes
- Life time(cycles): ≥10k
- Material of outer tube: 6063Aluminium
- Operating temperature(°C)：-20°C~60°C
- Storage temperature(℃)：-40°C~70°C
- Certification: CE
-
High-Force Small Hydraulic Linear Actuator for Industrial Applications Introducing the SLA-TG-20S small hydraulic linear actuator, designed for exceptional performance and reliability in a variety of industrial applications. With a jacking force of 4000N and a retracting force of 1100N, this actuator is perfect for lifting platforms and industrial automation equipment. Equipped with a 12V/24V/48V DC motor…
-
Model: SLA-TG-32S
Input Voltage: 12V / 24V / 48V DC
Power: 300W / 800W
Stroke Length: Optional 50mm, 100mm, 150mm, 200mm, 250mm, 300mm, 400mm, 800mm (Customizable within 50mm-800mm range)
Jacking Force: 1T
Retracting Force: 0.5T
Speed: 10-12mm/s, 20-25mm/s
Protection Grade: IPx6
Operating Temperature: -30°C to +70°C
Duty Cycle: Long-term continuous use, up to 6 minutes at a time
Weight: 5-15 kg
-
Model: SLA-TG-40S
Input Voltage: 24V / 48V DC
Power: 300W / 800W
Stroke Length: Optional 50mm, 100mm, 150mm, 200mm, 250mm, 300mm, 400mm (Customizable within 50mm-400mm range)
Jacking Force: 1.8T
Retracting Force: 1T
Speed: 7-8mm/s, 15-18mm/s
Protection Grade: IPx6
Operating Temperature: -20°C to +60°C
Duty Cycle: Long-term continuous use, up to 6 minutes at a time
Weight: 5-15 kg
-
Model: SLA-TG-50S
Input Voltage: 24V / 48V DC
Power: 300W / 800W
Stroke Length: Optional 50mm, 100mm, 150mm, 200mm, 250mm, 300mm, 400mm (Customizable within 50mm-400mm range)
Jacking Force: 2.5T
Retracting Force: 1.5T
Speed: 5-6mm/s, 10-12mm/s
Protection Grade: IPx6
Operating Temperature: -30°C to +70°C
Duty Cycle: Long-term continuous use, up to 6 minutes at a time
Weight: 5-15 kg
-
- Model: SLA-TG-63S
- Input Voltage: 24V / 48V DC
- Power: 300W / 800W
- Stroke Length: Optional 50mm, 100mm, 150mm, 200mm, 250mm, 300mm (Customizable within 50mm-300mm range)
- Jacking Force: 4.5T
- Retracting Force: 2.8T
- Speed: 2-3mm/s, 6-7mm/s
- Protection Grade: IPx6
- Operating Temperature: -20°C to +60°C
- Duty Cycle: Long-term continuous use, up to 6 minutes at a time
- Weight: 5-15 kg
-
- Heavy Duty Electric Stroke Linear Actuator: Made of aluminum alloy, plenty of power unit allows it to push and pull up to 900N/225lbs. Low noise design, less than 50dB. IP54 protection against dust, water, and corrosion, not like others, we contains the mounting brackets.
- Linear Actuator Specification: Travel speed = 0.39 inches/sec (10 mm/s); Input Voltage: 12V DC. Rated power: 20W, maximum 30W; Stroke length = 50mm(2″); Retracted length = 155mm(6.2″); Extended Length=205mm(8.2“); Maximum current consumption: 3A; Maximum Load = 202lbs(900N)（stroke can be customized）
- Built-in Limit Switches: Cut off the power, this 12 volt actuator can be stopped at any position, with self-locking function
- Safe Use: Over current protection, overload protection, over-voltage protection. The linear motion actuator works in temperatures from -4°F to +167°F and can be installed on snowblower chutes, chicken coops, industrial equipment, solar panels, etc.
- Wide Application: The Linear Actuator is widely used for chicken Coop Doors, TV lift tables, massage beds, electric beds, medical chairs, electric equipment, micro-devices, electric sofas, camera frames, cameras and more
-
- Heavy Duty Electric Stroke Linear Actuator: Made of aluminum alloy, plenty of power unit allows it to push and pull up to 1200N. Low noise design, less than 50dB. IP68 protection against dust, water, and corrosion, not like others, we contains the mounting brackets.
- Linear Actuator Specification: Travel speed = 0.39 inches/sec (10 mm/s); Input Voltage: 12V DC. Rated power: 20W, maximum 30W; Stroke length = 50mm(2″); Retracted length = 155mm(6.2″); Extended Length=205mm(8.2“); Maximum current consumption: 3A; Maximum Load = 1200N
- Built-in Limit Switches: Cut off the power, this 12 volt actuator can be stopped at any position, with self-locking function
- Safe Use: Over current protection, overload protection, over-voltage protection. The linear motion actuator works in temperatures from -4°F to +167°F and can be installed on snowblower chutes, chicken coops, industrial equipment, solar panels, etc.
- Wide Application: The Linear Actuator is widely used for chicken Coop Doors, TV lift tables, massage beds, electric beds, medical chairs, electric equipment, micro-devices, electric sofas, camera frames, cameras and more
-
-
-
-
- WIDELY USED: commonly used in automotive, medical devices and engineering industry, agricultural machinery,industrial electric lifting system, medical electric bed, surgical bed, traction bed,electric sofa, electric lifting lever, electric booth, electric sunroof, electric wheelchair, etc.
- Maximum push/pull is up to 150kg/140kg, and five stroke length can be chosen.
- High quality metal material, high performance motor, built-in stroke switch.
- RELIABLE PERFORMANCE:High quality metal material,built-in stroke switch,high performance motor,the same characteristics of push and pull ,accurately positions the load at variable and repeatable locations within the full stroke.
- LOW NOISE DESIGN,noise level below 42 dB.
